Panasonic FP7 Series Command Reference Manual

10.16 BAND (Deadband Control)
■
Ladder diagram
■
Available operation units (●: Available)
Operatio
n unit
bit US SS UL SL SF DF
i ● ● ● ●
■
List of operands
Operand Description
S1 Device address where the lower limit is stored, or lower limit data
S2 Device address where the upper limit is stored, or upper limit data
S3 Device address where the input value is stored, or the input value data
D Output storage device address
■
Available devices (●: Available)
Operan
d
16-Bit device:
32-Bit
device:
(Note 1)
Integer
Real
numbe
r
St
rin
g
Index
modifie
r
(Note 2)
W
X
W
Y
W
R
W
L
W
S
S
D
D
T
L
D
U
M
WI
W
O
TS
C
S
TE
C
E
IX
(N
ote
3)
K
(N
ote
4)
Ｕ
H
(N
ote
5)
SF
(N
ote
6)
D
F
(N
ote
7)
" "
S1 ● ● ● ● ● ● ● ● ● ● ● ● ● ●
S2 ● ● ● ● ● ● ● ● ● ● ● ● ● ●
S3 ● ● ● ● ● ● ● ● ● ● ● ● ● ●
D ● ● ● ● ● ● ● ● ● ●
(Note 1) Cannot be specified when the operation unit is 16-bit integer (SS).
(Note 2) Only 16-bit devices, 32-bit devices, and integer constants can be modified. (Real number constants,
and character constants cannot be specified.)
(Note 3) Index register (I0 to IE)
(Note 4) Can be specified only when the operation unit is signed integer (SS, SL).
(Note 5) Can be specified only when the operation unit is integer (US, SS, UL, SL).
(Note 6) Can be specified only when the operation unit is a single-precision floating point real number (SF).
(Note 7) Can be specified only when the operation unit is a double-precision floating point real number (DF).
10.16 BAND (Deadband Control)
10-62 WUME-FP7CPUPGR-12
