Panasonic FP7 Series Command Reference Manual

19.11 Ethernet Function: I/O Allocation
■
I/O relays that are related to Ethernet functions
For using each function of the built-in ET-LAN, the following I/O areas are occupied.
Unit type
Application
Number of occupied words (Number of occupied
points)
Input Output
CPU unit
CPU unit
Built-in ET-
LAN
Common occupied area
1 word (16 points)
WX6
-
User connections 1 to 16
3 word (48 points)
WX7-WX9
3 word (48 points)
WY7 to WY9
User connections 17 to 216
Max. 26 words (416
points)
WX11 to WX36
Max. 26 words (416
points)
WX11 to WX36
(Note 1) Input/output contacts of the CPU unit are allocated for using the functions of each cassette.
Regardless of use of such functions, input occupies 10 words (160 points, WX0 to WX9) and output
occupies 10 words (160 points, WY0 to WY9).
(Note 2) Occupied area in the area of user connections 17 to 216 varies according to the number of used
connections.
(Note 3) The starting numbers of I/O contacts of each unit including the CPU unit can be changed by the
setting of tool software.
■
Common occupied areas that are used for Ethernet functions
When using the Ethernet-related functions, flags for confirming the initialization, connection of
network and the completion of preparation are allocated.
Address Application
X60 Disconnection detection relay 1 = Disconnect 0 = Connect
X61 Ethernet initialization active
1 = During
initialization
0 = Completed
X62 IP address established 1 = Establish 0 = Not establish
X63 TCP-NODELAY option 1 = Enabled 0 = Disable
X64 FTP server preparation done
1 = Preparation
done
0 = Unusable
X65 FTP client preparation done
1 = Preparation
done
0 = Unusable
X66 Reserved for system
X67 Reserved for system
X68 HTTP client preparation done
1 = Preparation
done
0 = Unusable
X69 Mail send (SMTP client) preparation done
1 = Preparation
done
0 = Unusable
X6A Reserved for system
X6B EtherNet/IP preparation done
1 = Preparation
done
0 = Other than
preparation done
19.11 Ethernet Function: I/O Allocation
19-26 WUME-FP7CPUPGR-12
