15.2 GPTRNS / pGPSEND /GPSEND (General-Purpose Communication
Send Instruction)
■
Ladder diagram (GPTRNS)
■
Ladder diagram (pGPSEND)
■
Ladder diagram (GPSEND)
(Note 1) The above figure shows the case that S1=U0 (CPU unit with built-in SCU) and S2=U1 (port number 1)
are specified by the UNITSEL instruction.
■
Available operation units (●: Available)
Operatio
n unit
bit US SS UL SL SF DF
i ● ●
(Note 1) When a negative value is specified for operand [n], it is necessary to specify an SS operation unit.
15.2 GPTRNS / pGPSEND /GPSEND (General-Purpose Communication
Send Instruction)
15-4 WUME-FP7CPUPGR-12
