List of operands
Operand Description
S Starting number for the device for storing the sent data
n
Number of bytes of the sent data, or starting number of the device where the amount of sent data is
stored
D Starting number of the device that stores the processing result (1 word)
■
Available devices (●: Available)
Operan
d
16-Bit device:
32-Bit
device:
Integer
Real
numbe
r
St
rin
g
Index
modifie
r
W
X
W
Y
W
R
W
L
W
S
S
D
D
T
L
D
U
M
WI
W
O
TS
C
S
TE
C
E
IX K Ｕ H SF
D
F
" "
S1 ● ● ● ● ● ● ●
n
(Note 1)
● ● ● ● ● ● ● ● ● ●
D
(Note
1)
● ● ● ● ● ● ●
(Note 1) Always 16-bit data/device, regardless of the specification of operation units [i].
■
Outline of operation
● Data are sent from the communication port to external devices.
● Data of [n] bytes are sent from the unit / communication port set by the UNITSEL instruction,
starting with the starting address (word address) of the sent data area specified by [S].
● Data to be sent are set by the user program, in the area starting with [S].
● The processing result is stored in the area specified by [D].
■
Processing
● The slot numbers and communication port numbers specified with UNITSEL instruction are
obtained from the system data register (SD).
● This instruction confirms that the general-purpose communication clear to send flag of a
specified communication port is ON and the general-purpose communication sending flag is
OFF.
● When sending is enabled, sent data is transferred to the send buffer of a communication port
and a request to send is executed.
15.2 GPTRNS / pGPSEND /GPSEND (General-Purpose Communication
Send Instruction)
