3.7 / (NOT)

■

Ladder diagram

■

Outline of operation

● The / instruction inverts the preceding operation result.

■

Operation Example

X100

Y110

Y111

When X100 is ON, Y110 is ON and Y111 is OFF.

3.7 / (NOT)

WUME-FP7CPUPGR-12 3-11
