12.7 TIMEWT (Setting of Clock/Calendar)
■
Ladder diagram
■
List of operands
Operand Description
S Starting device address of clock data
(Note 1) Only this instruction comprises 7 words in total, including day of week. For details of clock data, refer
to "19.2 Clock and Time Data"
■
Available devices (●: Available)
Operan
d
16-Bit device:
32-Bit
device:
Integer
Real
numbe
r
St
rin
g
Index
modifie
r
W
X
W
Y
W
R
W
L
W
S
S
D
D
T
L
D
U
M
WI
W
O
TS
C
S
TE
C
E
IX K Ｕ H SF
D
F
" "
S ● ● ● ● ● ● ● ● ● ●
■
Outline of operation
● The clock data (year, month, day, hours, minutes and seconds), stored in the area starting
with [S], is set as RTC data for the CPU unit.
● The range of clock data that can be set for the calendar timer of the FP7 CPU unit is as
follows:
2000/1/1 00:00:00 to 2099/12/31 23:59:59
