Processing
6
1
2
3
4
5
K 0
K 1
K 1
[S]…DT0
(year)
(month)
(day)
(hours)
(minutes)
(seconds)
Example) Specify 08:54:19, January 1, 2012
K 12
K 8
DT0
DT1
DT2
DT3
DT4
DT5
K 54
K 19
* 1 word
DT6
(day of week)
K 0
K 1
K 1
(year)
(month)
(day)
(hours)
(minutes)
(seconds)
K 12
K 8
K 54
K 19
(day of week)
Update
0
● Day-of-week data
Sat
Mon
Tue
Wed
Thu
Fri
Sun
■
Precautions for programming
● Consistency of the day of week data with the date is not checked.
■
Flag operations
Name Description
SR7
SR8
(ER)
To be set in the case of out-of-range in indirect access (index modification).
To be set when the clock data range is exceeded.
To be set when the day of week range is exceeded.
