Panasonic FP7 Series Command Reference Manual

3.26 JP/LBL (Jump/Label)
■
Ladder diagram
■
List of operands
Operand Description
n Label number (relative jump pointer to LBL)
■
Devices that can be specified (indicated by ●)
Operan
d
16-Bit device:
16-Bit
device:
Integer
Real
numbe
r
St
rin
g
Index
modifie
r
W
X
W
Y
W
R
W
L
W
S
S
D
D
T
L
D
U
M
WI
W
O
TS
C
S
TE
C
E
IX K
Ｕ
(N
ote
1)
H SF
D
F
" "
n ●
(Note 1) Can be specified only when the operation unit is unsigned integer (US, UL).
■
Outline of operation
● When the execution condition is ON, this instruction jumps to the label with the specified
number (LBL instruction).
● The program continues running from the instruction after the target label.
■
Operation Example
● When execution condition X101 turns ON, the program jumps to label 1.
3.26 JP/LBL (Jump/Label)
WUME-FP7CPUPGR-12 3-81
