14.8 ABIN (Conversion: Decimal ASCII → BIN)
■
Ladder diagram
■
Available operation units (●: Available)
Operatio
n unit
bit US SS UL SL SF DF
i ● ● ● ●
■
List of operands
Operand Description
S1 Starting number of the area that stores the ASCII code to be converted
S2 The area that stores the number of bytes to be converted, or the constant
D Area to store the conversion result
■
Available devices (●: Available)
Operan
d
16-Bit device:
32-Bit
device:
Integer
Real
numbe
r
St
rin
g
Index
modifie
r
(Note 1)
W
X
W
Y
W
R
W
L
W
S
S
D
D
T
L
D
U
M
WI
W
O
TS
C
S
TE
C
E
IX
K
(N
ote
2)
Ｕ
(N
ote
3)
H
(N
ote
4)
SF
D
F
" "
S1 ● ● ● ● ● ● ● ● ●
S2
(Note
5)
● ● ● ● ● ● ● ● ● ●
D ● ● ● ● ● ● ●
(Note 1) Only 16-bit devices, 32-bit devices, and integer constants can be modified. (Real number constants,
and character constants cannot be specified.)
(Note 2) Can be specified only when the operation unit is signed integer (SS, SL).
(Note 3) Can be specified only when the operation unit is unsigned integer (US, UL).
(Note 4) Can be specified only when the operation unit is an integer (US, SS, UL, SL).
(Note 5) To be handled as a 16-bit integer (US, SS), regardless of operation unit.
■
Outline of operation
● This instruction converts the ASCII code string into BIN data that express a decimal figure.
