● When using direct output (OT), it is necessary to select the setting to exclude this unit from
the target for I/O refresh when configuring the settings for the I/O map.
2.5.12 DT*.n Data register (bit specification)
● Refer to "2.6.2 DT*.n Data register (bit specification)".
2.5.13 LD*.n Link register (bit specification)
● Refer to "2.6.4 LD*.n Link register (bit specification)".
2.5 Explanations about Relays
2-26 WUME-FP7CPUPGR-12
