Panasonic FP7 Series Command Reference Manual

15.4 SEND (MEWTOCOL Master / MODBUS Master)
■
Ladder diagram
(Note 1) The above figure shows the case that S1=U0 (CPU unit with built-in SCU) and S2=U1 (port number 1)
are specified by the UNITSEL instruction.
■
Available operation units (●: Available)
Operatio
n unit
bit US SS UL SL SF DF
i ● ●
■
List of operands
Operand Description
S Starting address of the sender data area
n Amount of sent data
D1 Partner station number
D2 Starting address of the device in the receiver data area of the partner unit
D3 Starting address of the device area of the master unit that stores the execution result code (1 word)
■
Available word devices (●: Available)
Operan
d
16-Bit device:
32-Bit
device:
Integer
Real
numbe
r
St
rin
g
Index
modifie
r
W
X
W
Y
W
R
W
L
W
S
S
D
D
T
L
D
U
M
WI
W
O
TS
C
S
TE
C
E
IX K Ｕ H SF
D
F
" "
S ● ● ● ● ● ● ●
n ● ● ● ● ● ● ● ● ●
D1 ● ● ● ● ● ● ● ● ●
D2
(Note
1)
(N
ote
2)
● ●
(N
ote
2)
●
(N
ote
2)
●
D3 ● ● ● ● ● ● ●
15.4 SEND (MEWTOCOL Master / MODBUS Master)
WUME-FP7CPUPGR-12 15-21
