9.5 STC (Carry-Flag Set)

■

Ladder diagram

■

Outline of operation

This instruction turns ON SR9 (CY).

■

Flag operations

Name Description

SR9 (CY) To be set after this instruction is executed.

9.5 STC (Carry-Flag Set)

9-10 WUME-FP7CPUPGR-12
