Processing
F E D C B A 9 8 7 6 5 4 3 2 1 0
Example 1
）
Operation unit: 16 bits (US) (SRB is OFF)
[i]…US [D]…DT0 [n]…U3
DT0
0 1 0 1 1 0 0 0 0 1 1 1 1 0 0 0
Bit
BIN
State of the specified bit
SRB(＝)
ON(1) OFF(0)
Flag operation during execution
Example 2) Operation unit: 16 bits (US) (SRB is ON)
[i]…US [D]…DT0 [n]…U3
Bit
BIN
F E D C B A 9 8 7 6 5 4 3 2 1 0
DT0
0 1 0 1 1 0 0 0 0 1 1 1 0 0 0 0
Flag operation during execution
State of the specified bit
SRB(＝)
OFF(0) ON(1)
■
Flag operations
Name Description
SR7, SR8 (ER)
To be set in the case of out-of-range in indirect access (index modification).
To be set when [n] is out of the range.
SRB (=)
To be set when the test bit (Bit [n]) is '0'.
To be reset when the test bit (Bit [n]) is '1'.
9.4 BTT (Bit Test)
WUME-FP7CPUPGR-12 9-9
