Panasonic FP7 Series Command Reference Manual

(Note 1) The storage destinations shown above are for station number 1. 12 words are assigned to each
station and are stored in a 192-word area in order starting from the information for station number 1. In
addition, they occupy the 192-word area.
Items
PLC link station No. and storage destination
Station No. 1 Station No. 2 ----- Station No. 15 Station No. 16
Link area block number [D] [D+12] ----- [D+168] [D+180]
PLC link W0 maximum
station number
[D+1] [D+13] ----- [D+169] [D+181]
Range of link relays [D+2] [D+14] ----- [D+170] [D+182]
Range of link registers [D+3] [D+15] ----- [D+171] [D+183]
Link relay sending start
number
[D+4] [D+16] ----- [D+172] [D+184]
Size of link relay send
area
[D+5] [D+17] ----- [D+173] [D+185]
Link register sending start
number
[D+6] [D+18] ----- [D+174] [D+186]
Size of link register send
area
[D+7] [D+19] ----- [D+175] [D+187]
Reserved for system
[D+8] to [D
+11]
[D+20] to [D
+23]
-----
[D+176] to [D
+179]
[D+188] to [D
+191]
■
Flag operations
Name Description
SR7
SR8
(ER)
Out-of-range in indirect access (index modification)
Destination range is out of the accessible range.
SCU unit does not exist in the slot specified by UNITSEL.
COM port specified by UNITSEL does not exist.
The parameter storage device specified by [D] is invalid.
15.9 PMGET (Acquiring SCU Parameters)
15-64 WUME-FP7CPUPGR-12
