Panasonic FP7 Series Command Reference Manual

■
Acquired data (PLC link time interval information): When [S] = 4
Storage
locatio
n
Items Range: Description
[D]
RING counter for the
number of receptions
U0 to
U65535
The number of receptions is stored. When the value exceeds
65535, it returns to 0.
[D+1]
Current receive
interval (x 1 ms)
-
The reception interval is stored.[D+2]
Minimum receive
interval (x 1 ms)
-
[D+3]
Maximum receive
interval (x 1 ms)
-
[D+4]
RING counter for the
number of
transmissions
U0 to
U65535
The number of transmissions is stored. When the value
exceeds 65535, it returns to 0.
[D+5]
Current send interval
(x 1 ms)
-
The send interval is stored.[D+6]
Minimum send interval
(x 1 ms)
-
[D+7]
Maximum send interval
(x 1 ms)
-
■
Acquired data (PLC link setting parameter monitoring information): When [S] = 5
Storage
locatio
n
Items Range: Description
[D]
Link area block
number
U0, U1
HFFFF
The block number of the link relay/link register area is stored.
U0, U1: Block number of the master unit
HFFFF: Other units
[D+1]
PLC link W0 maximum
station number
U2 to U16 Values out of the range are handled as "16".
[D+2] Range of link relays U0 to U64
Specify the range of link relays used for communication
(specification by number of words, relative values within the
specified block)
[D+3] Range of link registers U0 to U128
Specify the range of link registers used for communication
(relative values within the specified block)
[D+4]
Link relay sending start
number
U0 to U63
Link relay sending start number (specification by number of
words, relative value within the specified block)
[D+5]
Size of link relay send
area
U0 to U64
Size of link relay send area (specification by number of
words)
[D+6]
Link register sending
start number
U0 to U127
Link register sending start number (specification by number of
words, relative value within the specified block)
[D+7]
Size of link register
send area
U0 to U127
Size of link register send area (specification by number of
words)
[D+8] to
[D+11]
Reserved for system - Reserved area
