Panasonic FP7 Series Command Reference Manual

Storage
locatio
n
Items Range: Description
Bit 6: Transmission error (0 = Normal, 1 = Error)
Bit 7: Procedural error (0 = Normal, 1 = Error)
Bit 15 to 8: Not used
[D+3] Transmission error flag
H0000 to
H0003
Bit 0: Link 0 (0 = Normal, 1 = Error)
Bit 1: Link 1 (0 = Normal, 1 = Error)
Bit 15 to 2: Not used
[D+4]
Transmission
assurance flag by
station
H0000 to
H00FF
Bit 0: Station number 1 (0: Stop, Error state, 1: Normal
transmission state)
:
Bit 15: Station number 16 (0: Stop, Error state, 1: Normal
transmission state)
[D+5]
Station PLCs
Operation mode flag
H0000 to
H00FF
Bit 0: Station number 1 (0: PROG mode, 1: RUN mode)
:
Bit 15: Station number 16 (0: PROG mode, 1: RUN mode)
[D+6]
Station PLCs
Operation state flag
H0000 to
H00FF
Bit 0: Station number 1 (0: Normal, 1: Error)
:
Bit 15: Station number 16 (0: Normal, 1: Error)
[D+7] Area overlap flag
H0000 to
H00FF
Bit 0: Station number 1 (0: Normal, 1: Area overlap occurs
(Position of partner unit is ON.)
:
Bit 15: Station number 16 (0: Normal, 1: Area overlap occurs
(Position of partner unit is ON.)
■
Acquired data (PLC link error frequency information): When [S] = 3
Storage
locatio
n
Items Range: Description
[D] Number of lost tokens
U0 to
U65535
The number of occurrences of each error is stored.
[D+1]
Number of duplicate
tokens
[D+2]
Number of no signal
states
[D+3]
Number of times of
receptions of
undefined commands
[D+4]
Number of sum check
errors for reception
[D+5]
Number of received
data format errors
[D+6]
Number of
transmission errors
[D+7]
Number of procedural
errors
[D+8]
Number of duplicate
parent units
15.9 PMGET (Acquiring SCU Parameters)
15-62 WUME-FP7CPUPGR-12
