Panasonic FP7 Series Command Reference Manual

Example 3) Adding data to the existing CIP message. (Data other than character
string data is written in 4 bytes)
[S1]... DT1 [S2]... H0004 [D]...DT100
S1: Data to be added S2: Format of the data to be
added
D: CIP message storage destination
Value Value Value
DT1 00H 03H S2 0004H DT100 0003H
Data
length
DT2 32H (2) 31H (1) DT101 0001H
Written
data
DT3 00H 33H (3) DT102 12H 'A'
DT103 56H 34H
DT104 90H 78H
Operation result
S1: Data to be added D: CIP message storage destination
Value
Move data equivalent to 4 bytes
Value
DT1 00H 03H DT100 0003H→0007H
Data
length
DT2
32H (2) 31H (1)
DT101 0001H
DT3 00H 33H (3) DT102 03H 'A'
DT103
31H
00H
DT104 90H
32H
17.33 CIPMSET [CIP Message Data Setting (Merging)]
17-166 WUME-FP7CPUPGR-12
