CIP message send data format
Value
D CIP data length
D+1 Service code
} CIP receive header
D+2 General Status
D+3 onward CIP data
Complex data consisting of short type, double type, and string data type
Value
DT0 0011H
Data length
Stores the following three
data items as CIP message
data:
DT1
CIP receive header
DT2
DT3 0001H
1st data: '1'
● 1
● AB
● 1234H
DT4 02H 31H (1)
(Note): The starting one word of the character string
data is for the character string length.
DT5 41H (A) 00H
2nd data: 'AB'
DT6 34H 42H (B)
(Note): The starting one word of the character string
data is for the character string length.
DT7 ffH 12H
3rd data: 1234H
S2: Specify the data format and data size of the data to be acquired.
Specified range: 0 to 504 (000H to 1F8H)
Set value Description
0 Character string
Specify when acquired data is character strings.
Acquire data equivalent to “Starting device value of S1 + 2”.
1 to 504 Other than character string
Specify when acquired data is other than character strings.
Acquire data equivalent to “set value”.
D1: Specify the device that stores the data acquisition starting position.
Update the data equivalent to the number of data acquired after the instruction is completed.
Starting data length size is not included in the starting position.
17.34 CIPMGET (CIP Message Data Getting)
