Flag operations
Name Description
SR3A (SD memory card access
instruction execution in progress)
Turns ON when instruction execution starts. Turns OFF when
instruction execution is complete.
SR3B (SD memory card access
instruction execution complete)
Turns OFF when instruction execution starts. Turns ON when
instruction execution is complete.
SR3C (SD memory card access
instruction execution result)
Indicates the execution results when instruction execution is
complete. Normal end = 0, abnormal end = 1
SR7, SR8 (ER)
To be set in case of out-of-range values in indirect access (index
modification).
18.13 CFREE (Acquiring SD Memory Card Free Space)
WUME-FP7CPUPGR-12 18-57
