Word Range:
DT3 Hours 0 to 23
DT4 Minutes 0 to 59
DT5 Seconds 0 to 59
■
Format of time data
● One-word 16-bit binary data are allocated to each unit (hours, minutes and seconds), and
the overall time data are handled in the unit of 3 words.
● Hours data can be specified in the range from 0 to 9999.
Example) DT0 is specified for operand
Word Range:
DT0 Hours 0 to 9999
DT1 Minutes 0 to 59
DT2 Seconds 0 to 59
19.2 Clock and Time Data
19-4 WUME-FP7CPUPGR-12
