Panasonic FP7 Series Command Reference Manual

DF
DF
X100
X101
Y110
(3) Example 3 using DF instruction
→ When the leading edge differential is set for each input information (X100, X101)
■
Examples of applying differential instructions
● Using differential instructions makes it easy to create and adjust programs.
<Example of application to a self-holding circuit>
● Using a differential instruction allows longer input signals to be supported.
3.8 DF, DF/ (Leading Edge Differential, Trailing Edge Differential), DFI
(Leading Edge Differential (Initial Execution Type))
WUME-FP7CPUPGR-12 3-15
