(2) Processing is done with Y110 to be OFF.
(3) Processing is done with Y110 to be ON.
■
Use SET and RST instructions with differential instructions
● Putting the differential DF instructions before the SET and RST instructions makes it easy to
create and adjust the program.
● This is particularly effective when the same output destination is used in several places in the
program.
3.15 SET, RST (Set, Reset)
WUME-FP7CPUPGR-12 3-33
