Panasonic FP7 Series Command Reference Manual

■
Timing chart
Active
PB1
Active
Waiting
Waiting
PB2
PB3
Active
Scan 1 Scan 2
Scan 3
Scan 4
Scan 5
Scan 6
PB1 PB3
PB1 PB3 PB1 PB3
PB1
PB3 PB1 PB3
PB1
PB3
X 100
R 100
R 101
SR16
SR17
SR1001
SR1002
SR1003
PB2
PB2
PB2
(1)
(2)
Y 100
Y 101
(Note 1) SR1001 to SR1003: Program block active relays of PB1 to PB3
(Note 2) (1) PB1 executes STARTPG instruction, (2) PB1 executes STOPPG instruction.
(Note 3) PB2 clears the output in the 1st scan after the state is changed to waiting. (Program block active relay
is OFF.)
3.43 STARTPG (PBn Execution Start), STOPPG (PBn Execution Stop)
WUME-FP7CPUPGR-12 3-129
