Outline of operation
● This instruction transfers the operation unit data specified by [i] from the device address or
the constant specified by [S] to the device address specified by [D].
[S] → [D]
■
Processing
Example 1) When the operation unit is 16-bit (US, SS)
Example 2) When the operation unit is 32-bit (UL, SL, SF)
■
Flag operations
Name Description
SR7
SR8
(ER)
To be set in the case of out-of-range in indirect access (index modification).
5.1 MV (Data Transfer)
WUME-FP7CPUPGR-12 5-3
