Processing
Example 1) When the operation unit is 16-bit (US, SS)
Example 2) When the operation unit is 32-bit (UL, SL, SF)
H 00000000
H 11223344
H 55667788
H 9900AABB
H CCDDEEFF
H 12345678
DT0･DT1
DT2･DT3
DT4･DT5
DT6･DT7
DT8･DT9
[D]…DT6
[i]…UL,SL,SF
H 11223344
H 55667788
H 9900AABB
H 12345678
* In the case of SF, all 32 bits are 0 (sign, exponent and mantissa parts are 0), resulting in 0.00e+00.
DT0･DT1
DT2･DT3
DT4･DT5
DT6･DT7
DT8･DT9
■
Flag operations
Name Description
SR7
SR8
(ER)
To be set in the case of out-of-range in indirect access (index modification).
