Precautions for programming
● In the case of a direct address and index modification address, specify the same device for
[S1] and [S2]. At the same time, specify [S2] to be greater than or equal to [S1].
■
Flag operations
Name Description
SR7
SR8
(ER)
To be set in case of out-of-range values in indirect access (index modification).
To be set when [S1] is larger than [S2].
To be set when the destination range is outside the accessible range.
5.12 BKMV16 (Block Transfer (32-bit Data to 16-bit Data))
WUME-FP7CPUPGR-12 5-29
