Processing
Example 1) Operation unit: 16 bits (SS) Example 2) Operation unit: 32 bits (SL)
■
Precautions for programming
● The result should be the minimum negative value if it has been specified.
■
Flag operations
Name Description
SR7
SR8
(ER)
To be set in the case of out-of-range in indirect access (index modification).
7.2 NEG (Sign Inversion)
WUME-FP7CPUPGR-12 7-5
