Example 1) Operation unit: Signed 16 bits (SS) Example 2) Operation unit: Signed 32
bits (SL)
■
Precautions for programming
● The same value for unsigned integers (US, UL) is stored.
■
Flag operations
Name Description
SR7
SR8
(ER)
To be set in the case of out-of-range in indirect access (index modification).
To be set when the minimum negative value is specified for [S].
7.3 ABS (Absolute Value)
WUME-FP7CPUPGR-12 7-7
