Processing
00010001
00010010
15･･････8
00000000
00000000
DT10
DT11
7･･････0
00010001
15･･････8
00010010
7･･････0
DT20
Example 1)
[S]…DT10 [n]…U2
[D]…DT20
00010011 00010010
00010011
00010001
00010010
15･･････8
00000000
00000000
DT10
DT11
7･･････0
31･･････24
00000000
23･･････16
DT21
Example 2)
[S]…DT10 [n]…U3
[D]…DT20
00000000
DT12
00010001
15･･････8
7･･････0
DT20
Padded with "0".
■
Flag operations
Name Description
SR7
SR8
(ER)
To be set in the case of out-of-range in indirect access (index modification).
To be set when [n], the number of data to be unified, is out of the specified range.
