[S1]…DT10 [S2]…DT19
Example 5) Operation unit: Single-precision, floating-point real number (SF)
[S3]…U1 (Descending order)
SF 3.33
SF 11.11
SF 2.22
SF 1111 .1
SF 4.44
DT10・DT11
DT12・DT13
DT14・DT15
DT16・DT17
DT18・DT19
<Before sort> <After sort>
SF 1111 .1
SF 11.11
SF 4.44
SF 3.33
SF 2.22
DT10・DT11
DT12・DT13
DT14・DT15
DT16・DT17
DT18・DT19
[i]…SF
■
Precautions for programming
● It must be noted that, since the time for data comparison increases in proportion to the
square of the number of data, the sorting process can take a long time when there is a large
amount of data to be sorted.
● During sort execution, data in [S1] to [S2] are sorted in sequence according to the sort
conditions.
● The end position of the sort range is the device that contains [S2].
Example) When the operation unit is 32 bits, the sort range is the same whether a device
number of higher level or lower level is specified.
H CCDDEEFF
H 11223344
H 55667788
H 9900AABB
H CCDDEEFF
H 12345678
DT0・DT1
DT2・DT3
DT4・DT5
DT6・DT7
DT8・DT9
[S1]…DT2 [S2]…DT6
H 11223344
H 55667788
H 9900AABB
H 12345678
[S1]…DT2 [S2]…DT7
Sort targets Sort targets
DT0・DT1
DT2・DT3
DT4・DT5
DT6・DT7
DT8・DT9
■
Flag operations
Name Description
SR7
SR8
(ER)
To be set in the case of out-of-range in indirect access (index modification).
To be set when [S1] is larger than [S2].
To be set when the [S1] device and the [S2] device differ.
