Example of processing

■

Flag operations

Name Description

SR7

SR8

(ER)

To be set in case of out-of-range values in indirect access (index modification).

To be set when a non-real number is specified for [S].

11.22 STOD (Conversion: Single-precision Real Number Data → Double-

precision Real Number)

11-46 WUME-FP7CPUPGR-12
