Operation unit Minimum value Maximum value
US 0.00 65535.49
SS -32768.49 32767.49
UL 0.00 4294967295.49
SL -2147483648.49 2147483647.49
■
Example of processing
Example 1) Unsigned 16 bits (US) (positive value)
Example 2) Unsigned 16 bits (US) (negative value)
Operation error occurs if an unsigned integer is specified for the operation unit and a negative
value is converted.
Example 3) Signed 16 bits (SS) (positive value)
11.33 DROFF (Conversion: Double-precision Real Number → Integer (Round
to the Nearest Unit))
WUME-FP7CPUPGR-12 11-79
