Processing
Example 1) Taking out the last five characters from the DT0 string to transfer them
to DT20
"B" "A" "E" "D"
"1"
"2"
"3"
8 (No. of characters)
DT0
DT1
DT2
DT3
DT4
DT5
DT6
5 (No. of characters)
Characters to search
String table that is searched
DT20
DT21
DT22
DT23
DT24
DT25
DT26
"D"
"1"
"3"
"C"
"E"
"2"
[S1]...DT0 [S2]...U5
[D]...DT20
Byte address High Low Byte address High Low
Example 2) The number of characters of [S2] is larger than the number of characters
in the string of [S1]
"B" "A" "B" "A"
"C"
3 (No. of characters)
DT0
DT1
DT2
DT3
DT4
DT5
3 (No. of characters)
Characters to search
String table that is searched
DT20
DT21
DT22
DT23
DT24
DT25
"C"
[S1]...DT0 [S2]...U7 [D]...DT20
Byte address High Low Byte address High Low
■
Precautions for programming
● The character data of the [D] area from before performing the operation is overwritten.
● When the number of characters of [S2] is greater than the number of characters in the string
of [S1], the transferal is performed for the number of characters of [S1].
■
Flag operations
Name Description
SR7
SR8
(ER)
To be set in the case of out-of-range in indirect access (index modification).
To be set when the destination range is outside the accessible range.
To be set when [S2] (number of characters) is out of the range.
