Processing
Example 1) Taking out the first five characters from the DT0 string to transfer them
to DT20
"B" "A"
"B" "A"
"C"
"D"
"E"
8 (No. of characters)
DT0
DT1
DT2
DT3
DT4
DT5
DT6
5 (No. of characters)
Characters to search
String table that is searched
DT20
DT21
DT22
DT23
DT24
DT25
DT26
"D"
"1"
"3"
"C"
"E"
"2"
[S1]...DT0
[S2]...U5
[D]...DT20
Byte address High Low Byte address High Low
Example 2) The number of characters of [S2] is larger than the number of characters
in the string of [S1]
"B" "A" "B" "A"
"C"
3 (No. of characters)
DT0
DT1
DT2
DT3
DT4
DT5
DT6
3 (No. of characters)
Characters to search
DT20
DT21
DT22
DT23
DT24
DT25
DT26
"C"
[S1]...DT0
[S2]...U7 [D]...DT20
String table that is searched
Byte address High Low Byte address High Low
Precautions for programming
The character data of the [D] area from before performing the operation is overwritten.
When the number of characters of [S2] is greater than the number of characters in the string
of [S1], the transferal is performed for the number of characters of [S1].
Flag operations
Name Description
SR7
SR8
(ER)
To be set in the case of out-of-range in indirect access (index modification).
To be set when the destination range is outside the accessible range.
To be set when [S2] (number of characters) is out of the range.
14.22 LEFT (Takeout of the Left Side of a String)
WUME-FP7CPUPGR-12 14-95
