● Up to 16 send instructions can be performed to different COM ports and connections
simultaneously. (The total of simultaneous usage of SEND, RECV, pPSEND, GPTRNS, and
pPMSET instructions)
● For FP7 multi-wire link unit, only one of those instructions can be executed for one unit at a
time.
■
Flag operations
Name Description
SR7
SR8
(ER)
To be set in the case of out-of-range in indirect access (index modification).
To be set when the destination range is outside the accessible range.
To be set when the FP7 multi-wire link unit that is specified by UNITSEL does not exist.
To be set when the partner unit station number that is specified by [S1] is out of the range.
To be set when the source data device of the partner unit specified by [S2] is incorrect.
To be set when the amount of sent data specified by [n] is incorrect.
To be set when the data device in the receiver data area in the master unit specified by [D1]
is incorrect or exceeds the area.
To be set when the result storing device that is specified by [D2] is incorrect.
To be set when the type (1-bit or 16-bit) of the specified device is different between [S2] and
[D1].
16.2 RECV (When FP7 Multi-wire Link Unit Is Used)
WUME-FP7CPUPGR-12 16-9
