Panasonic FP7 Series Command Reference Manual

[S] value Type of acquired data
Number of stored
data
Storage location
0 Number of F link services 1 word [D]
1 F link operation state monitor 10 word [D] to [D+9]
■
Acquired data (number of F link services): When [S] = 0
Storage
location
Items Range: Description
[D] F link service counter U0 to U65535 Service ring counter of master unit
■
Acquired data (F link operation state monitor): When [S] = 1
Storage
location
Items Range: Description
[D] to [D+1] Connected unit
H0 to
HFFFFFFFF
Bit 0 to bit 31: Unit number 1 to unit number 32
OFF: Disconnected unit
ON: Connected unit
[D+2] to [D
+3]
Abnormal unit current value
Bit 0 to bit 31: Unit number 1 to unit number 32
OFF: Normal unit
ON: Abnormal unit
[D+4] to [D
+5]
Abnormal unit cumulative
value
[D+6] to [D
+7]
Setting of slave unit where
I/O verification error occurred
[D+8] to [D
+9]
Slave unit where
instantaneous power failure
occurred
■
Flag operations
Name Description
SR7
SR8
(ER)
To be set in the case of out-of-range in indirect access (index modification, pointer access).
To be set when the destination range is outside the accessible range.
To be set when the FP7 multi-wire link unit does not exist in the slot that is specified by
UNITSEL.
To be set when the COM port specified by UNITSEL does not exist.
To be set when the parameter storing device that is specified by [D] is invalid.
16.5 PMGET (Acquiring MEWNET-F Parameters)
WUME-FP7CPUPGR-12 16-19
