PerkinElmer LabChip GX User Manual

Troubleshooting and Diagnostics 293
V4.2 LabChip GX User Manual PerkinElmer
System Components Test
Any chip can be loaded
Chip Interface Test
Remove Chip
Disk Space Check Available disk space below 4 GB. Risk of
losing data as disk space is used. Free
space on local hard drive.
Description Potential Cause of Failure
Verify Fan Operation Damaged fan. Contact PerkinElmer
Technical Support (see page 3).
Check Chip Cartridge
Interlock
Chip Drawer is not open or closed at the
correct time. Close or open chip drawer
as instructed.
Interlock Switch is defective. Contact
PerkinElmer Technical Support (see
page 3).
Description Potential Cause of Failure
Marker Pressure
Sensor Test
Pressure sensor out of calibration.
Contact PerkinElmer Technical Support
(see page 3).
Marker Pressure Chip
Interface Clog Test
Clog in pressure line. Contact
PerkinElmer Technical Support (see
page 3).
Priming Pressure
Sensor Test
Pressure sensor out of calibration.
Contact PerkinElmer Technical Support
(see page 3).
Priming Pressure Chip
Interface Clog Test
Clog in pressure line. Contact
PerkinElmer Technical Support (see
page 3).
Sipping Pressure
Sensor Test
Pressure sensor out of calibration.
Contact PerkinElmer Technical Support
(see page 3).
Sipping Pressure Chip
Interface Clog Test
Clog in pressure line. Contact
PerkinElmer Technical Support (see
page 3).
