Data Analysis 47
V4.2 LabChip GX User Manual PerkinElmer
How the Software Analyzes Protein Data
(Continued)
Figure 12. Standard Curve - Protein
6 A Lower Marker is the internal standard used to align the ladder
data with data from the sample wells. Figure 13 shows an
example of the assigned Lower Marker peak (marked LM) in a
sample well.
Figure 13. Markers - Protein
