Special Adjustments
SM 5-121 D093/D094
Replacement
and
Adjustment
To Correct Pattern Density
1. Do SP2943-1, -2, and -3
This SP makes the output of each LPH block brighter or darker.
2. Adjust the density for LPH 1 with SP2943-1.
If the density is too dark, set a smaller value.
If the density is too light, set a larger value.
3. Do SP2902-2, select Pattern #10, touch [OK], then print the pattern by feeding the blank
sheet and check the density.
4. Do this procedure for LPH2 and LPH3 until the density is the same in each of the three
sections.
LPH2: SP2943-2
LPH3: SP2943-3
To Next Page
