SP6-xxx Peripherals
SM Appendix
2-189
D093/D09
4
Appendix:
SP Mode
Ta
b
l
e
s
2.7 SP6-XXX
PERIPHERALS
6969
Bypass Feed Setting
DFU
This sets the how the byp
ass feed sensors read paper sizes.
[0 to 1/0/1]
0: DOM, EU (Japan, Europe)
1: NA
(North
America)
Other Group 6000 SP codes may be display
ed but are not used with this machine.
(These other SP codes are for peripheral uni
ts not support by this machine at the
present time. July 2010)
710
712
