Jam Code Tables, Cover Open
D093/D094 7-56 SM
7.4.4 COVER OPEN
Location Shuts Off Lines Display
Drawer Connector
Roll feed motor, cutter motor, roll feed clutches
(24 V dc line)
Cover Open
Exit Cover Sensor
Cooling fan, paper junction gate solenoid,
quenching lamp, pick-off pawl solenoid, fusing
motor, T&S power pack (24 V dc line), fusing
lamp (power relay/ac line)
Exit Cover Switch
Exit Unit Switch
Scanner Switch Scanner motor (24 dc line)
Toner Hopper Cover
Switch
Toner supply clutch, paper registration clutch,
drum motor, main motor, CGB power pack (24
V dc line)
Upper Unit Sensor Toner supply clutch, paper registration clutch,
drum motor, main motor, CGB power pack,
cooling fan, paper junction gate solenoid,
quenching lamp, pick-off pawl solenoid, fusing
motor, T&S power pack (24 V dc line), fusing
lamp (power relay/ac line)
Upper Unit Switch
