Board LEDS, DIP Switches
D093/D094 7-78 SM
LED Color LED Definition LED State
LED 4 RED BIOS Post Code Normal: ON
Installing: ON or FLASH
Installation END: ON
LED 5 RED BIOS Post Code Normal: ON
Installing: OFF
Installation END: ON
LED 6 RED BIOS Post Code Normal: ON
Installing: OFF
Installation END: ON
LED 7 RED BIOS Post Code Normal: OFF
Installing: OFF
Installation END: ON
LED 8 RED BIOS Post Code Normal: FLASH
Installing: FLASH
Install END: FLASH
LED 9 RED BIOS/OS Distinction Normal: FLASH
Installing: FLASH
Install END: FLASH
LED 10 GREEN Power On Normal: ON
Installing: ON
Installation END: ON
LED 11 YELLOW Flash LED Normal: FLASH
Installing: FLASH
Install END: FLASH
