SP4-xxx Scanner
SM Appendix 2-103 D093/D094
Appendix:
SP Mode
Tables
4965 Scan Speed Switch Correction
The original feed roller tries to adjust for slippage of the feed rollers to allow the
machine measure the length of the original accurately. The diameter of the feed
roller (32 ±0.05) differs slightly from the diameter of the exit roller (32 ±0.05). The
slightly higher speed of the exit roller could cause the original to feed faster than
usual, and cause distortion of the image at the joints of the CIS. Use this SP to
lower the speed of the original to correct this problem if image distortion at the
CIS joints occurs.
When to Use This SP
Adjust this SP if you see image distortion after replacing the original feed
roller or exit roller.
You may also need to adjust this SP if you see image distortion after CIS
adjustments with SP4972.
For more about how to use SP4965, please refer to "Replacements and
Adjustments" > "Scanner", "Original Feed Unit Rollers".
[-1.0 to 0.0/ -0.2 /0.1]
1 Leading Edge
The original feed roller tries to adjust for slippage of the feed rollers to allow the
machine measure the length of the original accurately. The diameter of the feed
roller (32 ±0.05) differs slightly from the diameter of the exit roller (32 ±0.05). The
slightly higher speed of the exit roller could cause the original to feed faster than
usual, and cause distortion of the image at the joints of the CIS. Use this SP to
lower the speed of the original to correct this problem if image distortion at the
CIS joints occurs.
When to Use This SP
Adjust this SP if you see image distortion after replacing the original feed
roller or exit roller.
You may also need to adjust this SP if you see image distortion after CIS
adjustments with SP4972.
[-1 to 0 / -0.2 / 0.1%]
