Autoreclosing
Settings and Relay Word Bits for Autoreclosing and Manual Closing
FOLBK1 Follower Breaker = Breaker 1
FOLBK2 Follower Breaker = Breaker 2
NBK0 No Breaker Active in Reclose Scheme
NBK1 One Breaker Active in Reclose Scheme
NBK2 Two Breakers Active in Reclose Scheme
LLDB1 Live Line—Dead Bus 1 (59L AND 27BK1)
DLLB1 Dead Line—Live Bus 1 (27L AND 59BK1)
DLDB1 Dead Line—Dead Bus 1 (27L AND 27BK1)
LLDB2 Live Line—Dead Bus 2 (59L AND 27BK2)
DLLB2 Dead Line—Live Bus 2 (27L AND 59BK2)
DLDB2 Dead Line—Dead Bus 2 (27L AND 27BK2)
a
Only applicable to products that support single-pole reclosing.
Table 6.24 Autoreclose Logic Relay Word Bits (Sheet 3 of 3)
