11.70
SEL-421 Relay Instruction Manual Date Code 20171021
Relay Word Bits
Row Lists
Table 11.66 Relay Word Bits: Bay Control Disconnect Bus-Zone Compliant
Row Name Description
342 89CLB01–89CLB08 Disconnect 1–8 bus-zone protection
343 89CLB09–89CLB10 Disconnect 9–10 bus-zone protection
343 * Reserved
343 * Reserved
343 * Reserved
343 * Reserved
343 * Reserved
343 * Reserved
Table 11.67 Relay Word Bits: Bay Control Disconnect Control (Sheet 1 of 3)
Row Name Description
344 89OC01 ASCII Open Disconnect 1 command
344 89CC01 ASCII Close Disconnect 1 command
344 89OCM01 Mimic Disconnect 1 open control
344 89CCM01 Mimic Disconnect 1 close control
344 89OPE01 Disconnect Open 1 output
344 89CLS01 Disconnect Close 1 output
344 89OCN01 Open Disconnect 1
344 89CCN01 Close Disconnect 1
345 * Reserved
346 89OC02 ASCII Open Disconnect 2 command
346 89CC02 ASCII Close Disconnect 2 command
346 89OCM02 Mimic Disconnect 2 open control
346 89CCM02 Mimic Disconnect 2 close control
346 89OPE02 Disconnect Open 2 output
346 89CLS02 Disconnect Close 2 output
346 89OCN02 Open Disconnect 2
346 89CCN02 Close Disconnect 2
347 * Reserved
348 89OC03 ASCII Open Disconnect 3 command
348 89CC03 ASCII Close Disconnect 3 command
348 89OCM03 Mimic Disconnect 3 open control
348 89CCM03 Mimic Disconnect 3 close control
348 89OPE03 Disconnect Open 3 output
348 89CLS03 Disconnect Close 3 output
348 89OCN03 Open Disconnect 3
348 89CCN03 Close Disconnect 3
349 * Reserved
350 89OC04 ASCII Open Disconnect 4 command
350 89CC04 ASCII Close Disconnect 4 command
350 89OCM04 Mimic Disconnect 4 open control
