Schweitzer Engineering Laboratories SEL-421-4 - Table 11.68 Relay Word Bits: Bay Control Disconnect Timers and Breaker Status

11.72
SEL-421 Relay Instruction Manual Date Code 20171021
Relay Word Bits
Row Lists
359 * Reserved
360 89OC09 ASCII Open Disconnect 9 command
360 89CC09 ASCII Close Disconnect 9 command
360 89OCM09 Mimic Disconnect 9 open control
360 89CCM09 Mimic Disconnect 9 close control
360 89OPE09 Disconnect Open 9 output
360 89CLS09 Disconnect Close 9 output
360 89OCN09 Open Disconnect 9
360 89CCN09 Close Disconnect 9
361 * Reserved
362 89OC10 ASCII Open Disconnect 10 command
362 89CC10 ASCII Close Disconnect 10 command
362 89OCM10 Mimic Disconnect 10 open control
362 89CCM10 Mimic Disconnect 10 close control
362 89OPE10 Disconnect Open 10 output
362 89CLS10 Disconnect Close 10 output
362 89OCN10 Open Disconnect 10
362 89CCN10 Close Disconnect 10
363 * Reserved
Table 11.68 Relay Word Bits: Bay Control Disconnect Timers and Breaker Status (Sheet 1 of 5)
Row Name Description
364 89CBL01 Disconnect 01 close block
364 89OSI01 Disconnect 01 open seal-in timer timed out
364 89CSI01 Disconnect 01 close seal-in timer timed out
364 89OIR01 Disconnect 01 open immobility timer reset
364 89CIR01 Disconnect 01 close immobility timer reset
364 89OBL01 Disconnect 01 open block
364 89ORS01 Disconnect 01 open reset
364 89CRS01 Disconnect 01 close reset
365 89OIM01 Disconnect 01 open immobility timer timed out
365 89CIM01 Disconnect 01 close immobility timer timed out
365 521CLSM Breaker 1 closed
365 521_ALM Breaker 1 status alarm
365 522CLSM Breaker 2 closed
365 522_ALM Breaker 2 status alarm
365 523CLSM Breaker 3 closed
365 523_ALM Breaker 3 status alarm
366 89CBL02 Disconnect 02 close block
366 89OSI02 Disconnect 02 open seal-in timer timed out
366 89CSI02 Disconnect 02 close seal-in timer timed out
Table 11.67 Relay Word Bits: Bay Control Disconnect Control (Sheet 3 of 3)
Row Name Description
