8.6
SEL-421 Relay Instruction Manual Date Code 20171021
Settings
Global Settings
Phasors Included in the Data q
Terminal Name, Relay Word Bit, Alternate Terminal Name
Specify the terminal for Synchrophasor measurement and transmission in the
synchrophasor data stream q.
This is a freeform setting category for enabling the terminals for synchrophasor
measurement and transmission. This freeform setting has three arguments. Spec-
ify the terminal name (any one of W, X, S, Y, or Z) for the first argument. Specify
any Relay Word bit for the second argument. Specify the alternate terminal name
(any one of W, X, S, Y, or Z) for the third argument.
The second and third arguments are optional unless switching between terminals
is required. Whenever the Relay Word bit in the second argument is asserted the
terminal synchrophasor data are replaced by the alternate terminal data.
Table 8.14 Synchronized Phasor Configuration Settings
Setting Prompt Default
MFRMT Message Format (C37.118, FM) C37.118
MRATE
a
a
Only available in MFRMT = C37.118.
Messages per Second (1, 2, 4, 5, 10, 12, 15, 20, 30, 60)
b
b
If NFREQ = 50 then the range is 1, 2, 5, 10, 25, 50.
2
PMAPP PMU Application (F, N, 1)
c
c
Option 1 is available only if MRATE = 60.
N
PMLEGCY
a
Synchrophasor Legacy Settings (Y, N) N
NUMPHDC
a,d
d
Only available if PMLEGCY = N.
Number of Data Configurations (1–5) 1
PMSTNq
a,e
e
q = 1–NUMPHDC. If PMLEGACY = Y, then these two settings become PMSTN and PMID.
Station Name (16 characters) STATION A
PMIDq
a,e
PMU Hardware ID (1–65534) 1
PHVOLT
f
f
Only available if PMLEGCY = Y.
Include Voltage Terminal (combo of Y,Z) Y
PHDATAV
f
Phasor Data Set, Voltages (V1, PH, ALL, NA) V1
PHCURR
f
Include Current Terminal (combo of W, X, S) W
PHDATAI
f
Phasor Data Set, Currents (I1, PH, ALL, NA) NA
Table 8.15 Phasors Included in the Data
Setting Prompt Default
PHDVq
a
a
q = 1–NUMPHDC.
Phasor Data Set, Voltages (V1, PH, ALL) V1
PHDIq
a
Phasor Data Set, Currents (I1, PH, ALL) ALL
PHNRq
a
Phasor Num. Representation (I = Integer, F = Float) I
PHFMTq
a
Phasor Format (R = Rectangular, P = Polar) R
FNRq
a
Freq. Num. Representation (I = Integer, F = Float) I
