IEC 61850 Object Changes
IEC 61850 Object Changes
The SEL-421-0, -1, -2, -3 implementation of the IEC 61850 protocol suite differs
slightly from the SEL-421-4, -5 implementation. Tabl e B.1 4 lists the main func-
tional changes between the two.
Default datasets may be used for MMS Reports or for GOOSE message transmis-
sion. Table B.15 lists the default dataset changes in the new ICD file version.
Note that the contents of any dataset may be modified via
ACSELERATOR Archi-
tect SEL-5032 Software.
Most of the Logical Nodes and Attributes remain the same between the two
implementations. Table B.16 lists the mapping changes in the new ICD file.
Table B.14 IEC 61850 Functional Differences
Top ic SEL-421-0, -1, -2, -3 SEL-421-4, -5
ICD File Version Version 001, 002 Version 003
Incoming GOOSE Mappable to
CCIN001–CCIN128
(binary data)
VB001–VB256 (binary data) RA001–
RA256 (analog data)
Outgoing GOOSE Relay Word bits mapped to
CCOUT001 (binary data)
N/A (Relay Word bits can be sent directly
without intermediate mapping; Analog
outputs also available (RAO01–RAO64)
SER Time stamps SER-quality time stamps
available only for LNs
included in the SER dataset
Any points in the SER list will have SER-
quality time stamps. Otherwise, accuracy
is within 500 ms.
Controls Normal Security Only Enhanced Security and Select-before-
operate (SBO) available
Table B.15 Default Dataset Differences
Default Dataset SEL-421-0, -1, -2, -3 SEL-421-4, -5
DSet03, DSet09 Includes LNs mapped from
Relay Word Bits BK1A, BK1B,
BK1C, BK2A, BK2B, BK2C
Includes LNs mapped from Relay
Word Bits DC1–DC8
DSet13 CCOUT Status Control and Annunciation
Table B.16 Logical Node Mapping Differences (Sheet 1 of 2)
LD SEL-421-1, -2, -3 Path
SEL-421-1, -2, -3
Mapping
SEL-421-4, -5 Path SEL-421-4, -5 Mapping
PRO BKR1PTRC2$ST$tr$general TRIP BKR1PTRC2$ST$tr$general Set (1) if TPA1 or TPB1 or TPC1
are set
PRO BKR2PTRC3$ST$tr$general TRIP BKR2PTRC3$ST$tr$general Set (1) if TPA2 or TPB2 or TPC2
are set
PRO BFR1RBRF1$ST$Str$general BFI3P1 BFR1RBRF1$ST$Str$general TRUE if (BFI3P1 OR BFIA1 OR
BFIB1 OR BFIC1), FALSE oth-
erwise
PRO BFR2RBRF2$ST$Str$general BFI3P2 BFR2RBRF2$ST$Str$general TRUE if (BFI3P2 OR BFIA2 OR
BFIB2 OR BFIC2), FALSE oth-
erwise
CON RBGGIO1$CO$SPCSO09 RB09 RBGGIO2$CO$SPCSO09 RB09
CON RBGGIO1$CO$SPCSO10 RB10 RBGGIO2$CO$SPCSO10 RB10
CON RBGGIO1$CO$SPCSO11 RB11 RBGGIO2$CO$SPCSO11 RB11
