7.15
Date Code 20171021 Instruction Manual SEL-421 Relay
Metering, Monitoring, and Reporting
Reporting
➤ Active group at the trigger instant
➤ Targets
Figure 7.7 is a sample event history from a terminal.
Fault location data can be indeterminate (for example, when you trigger an event
and there is no fault on the power system). If this is the case, the relay displays
$$$$.$$ for the Location entry in the event history. You will also see the $$$$.$$
display if the fault location enable setting EFLOC is N.
The event types in the event history are the same as the event types in the event
summary (see Table 7.10 for event types).
Figure 7.7 Sample Event History
Relay 1 Date: 03/16/2001 Time: 11:57:27.803
Station A Serial Number: 2001001234
# DATE TIME EVENT LOCAT CURR GRP TARGETS
10007 03/15/2001 23:30:49.026 BCG T 48.17 8892 1 INST TIME ZONE_1 B_PHASE
10006 03/15/2001 07:15:00.635 ABC T 22.82 8203 1 INST ZONE_1 A_PHASE bk1rs
10005 03/15/2001 06:43:53.428 TRIG $$$$.$$ 0 1
Event
Number
Event
Type
Fault
Location
Active
Group
