Firmware, ICD File, and Manual Versions
Instruction Manual
Instruction Manual
The date code at the bottom of each page of this manual reflects the creation or
revision date.
Table A.4 lists the instruction manual versions and revision descriptions. The
most recent instruction manual version is listed first.
ICD-421-R202-V0-Z310004-D20150323 ➤ Fix for RVRS3 and RVRS4 set
dirGeneral Data change true.
R310 004 20150429
ICD-421-R201-V0-Z000000-D20130430
b
➤ Certified by KEMA for IEC 61850
Conformance.
R313 005 20130627
ICD-421-R201-V0-Z000000-D20121207
b
➤ Added support for 128 incoming
GOOSE subscriptions, MMS authenti-
cation, and user-configurable GOOSE
filtering.
R313 005 20121214
ICD-421-R200-V0-Z000000-D20120220
b
➤ SEL-421-4/-5 ICD file for firmware
R310 or higher.
R310 004 20120223
ICD-421-R102-V0-Z000000-D20100118
b
➤ SEL-421-4/-5 ICD file for firmware
R300 or higher.
R300 003 20100308
configVersion Details:
ICD-[PN]-R[RN]-V[VS]-Z[FC]-D[RD] where:
[PN] = Product Name (e.g., 421)
[RN]
c
= Revision Number (e.g., 102)
[VS] = Version Specifications (e.g., 9)
[FC]
d
= Minimum Relay Firmware and Class File Version (e.g., 311005)
[RD] = Release Date Code (e.g., 20150219)
a
The configVersion can be determined for the IED by performing an "ID" ASCII command from a terminal connection.
b
The FC in this configVersion does not have a meaningful value.
c
This is the ICD file revision number, not IED firmware revision number.
d
FC consists of six digits. The first three following the Z represent the minimum IED firmware required to be used with the ICD (e.g., 516). The
second three represent the ICD ClassFileVersion (e.g., 005).
Table A.3 ICD File Revision History (Sheet 2 of 2)
configVersion
a
Summary of Revisions
Minimum
Relay
Firmware
ClassFileVersion
Manual
Date Code
Table A.4 Instruction Manual Revision History (Sheet 1 of 3)
Date Code Summary of Revisions
20171021
Appendix A
➤ Updated for firmware versions R321-V2 and R322-V3.
20171008
Section 10
➤ Updated Table 10.15 Logical Device: PRO (Protection) and Table 10.16 Logical Device: MET (Metering).
Section 12
➤ Updated Table 12.1: Analog Quantities Sorted Alphabetically and Table 12.2: Analog Quantities Sorted by Func-
tion for PRPMCC and PTPPORT.
Appendix A
➤ Updated for firmware version R323.
➤ Updated for ICD firmware version R300.
20170820
Appendix A
➤ Updated for firmware versions R317-V1, R319-V2, R320-V2, and R321-V1.
